EP1718J5

John 5 Signature Cable EP1710J5

Specs

- Wire Gauge: AWG 20 (0.519 mm2)
- Diameter: 0.237 in. (6.02 mm)
- Insulation: Polyethylene inner with PVC outer
- Capacitance: 33.27 pF/ft (109pF/M)
- Shield & Material: Copper Braid + Conductive PVC 78%
- Jacket & Material: PVC + Nylon Overbraid
- Resistance: 8.8 ohm/1,000 ft (29 ohm/KM)
- Inductance: 0.07 xB5H/ft (0.2 xB5H/M)
- Termination Method: Silver Solder
